Turbocharger Pulsar PSR 2860 Gen 2 Dual Ball Bearing – Compressor Housing T51R – Tubine Housing Dual V-Band 0.72 A/R IWG – PSR Billet Actuator 11.6psi
- Dual Ceramic Ball Bearing System
- 8 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
- Inconel 713c 9-blade Turbine Wheel
- Gen2 Cover Integrated with the Speed Sensor Port
- 0.64, 0.86A/R T25 Inlet, 5 Bolt Outlet, 0.64 A/R dual V-BAND stainless steel, 0.82 A/R dual V-BAND stainless steel, etc. turbine housings in option
- V-Band Flange kit(s) for the exhaust housing included
- Max Air Flow rate: ~40 lb/min, rated @ 475 FWHP
| Compressor Wheel: | 45.64/60.07/62mm |
| Turbine Wheel: | 54/47mm |
| Compressor Inlet: | 3 Hose |
| Compressor Outlet: | 2 Hose |
| Turbine Inlet: | 2.5 V-Band |
| Turbine Outlet: | 3 V-Band (3.55 OD) |
| Oil Feed: | -4 AN connect to the Oil Restrictor |
| Oil Drain: | Std T3 Flange |
| Water In/Outlet: | M14*1.5 |
We highly recommended running water cooling for better durability.
